Specification
Detail
Size: 120 × 120 × 25 mm.
Mounting hole distance: 105 × 105 mm.
Connector and pins: 4-pin PWM
Cable length: 20 cm. + NA-EC1 extension cable size 30 cm.
Bearing: SSO2
Impeller Shape: Progressive-Bend Impeller
Frame Technology: AAO (Advanced Acoustic Adjustment)
Material: Sterrox® LCP
Rotation speed (±10%) : 1800 rpm
Rotation speed when using LNA (±10%) : 1500 rpm
Air volume: 107.3 cubic meters per hour
Air volume when using LNA: 87.2 cubic meters per hour
Noise level: 22.5 decibels (A)
Noise level when using LNA : 18.1 decibels (A)
Static pressure: 3.14 mm H 2 O
Static pressure when using LNA : 1.71 mm H 2 O
Maximum power: 1.8 watts
Maximum current: 0.15 amps
Operating voltage: 12 volts
Average Lifespan (MTTF): More than 150,000 hours
Warranty : 6 Years
